HANO HN-HVS5 High Voltage Stackable Home Energy Storage System (IP-20)10.24kWh-30.72kWh Lithium Battery

HANO HN-HVS5 High Voltage Stackable Home Energy Storage System (IP-20)10.24kWh-30.72kWh Lithium Battery

Scalable Architecture: 10.64kWh to 37.27kWh per tower, expandable up to 5 towers in parallel.
Long Cycle Life: >6,000 cycles @80% DOD, ensuring a 15-20 year service life.
Advanced Safety: Built-in BMS, IP20 rated, and fully certified (IEC62619/CE/UN38.3).
High Power Output: Supports 100A max charge/discharge current with low internal resistance.
Wide Temperature Range: Operates reliably from -10°C to 55°C (discharge).
Easy Installation: Compact, stackable modular design for quick setup and maintenance.

Overview
Recommended Products

Model	HN-HVS5
Rated voltage(V)	204.8	307.2	409.6	512	614.4
Cell model(LFP-3.2V)	3.2V 50Ah 102.4V 5.12kWh
System configuration	64S1P	96S1P	128S1P	160S1P	192S1P
Number of Modules	2	3	4	5	6
Rate power(KWh)	10.24	15.36	20.48	25.6	30.72
Charge upper voltage	227.2V	340.8V	454.4V	568V	681.6V
Discharge lower voltage	182.4V	273.6V	364.8V	456V	547.2V
Recommended current	50A
Maximum charging current	100A
Maximum discharging current	100A
Operation temperature range	Charge:0~55℃
Operation temperature range	Discharge: -10~55℃
Cycle life(25℃)	＞6000 cycles @80% DOD
Protection level	IP20
	0℃~35℃
Storage humidity	10%RH~90%RH
Internal impedance	≤1Ω
Warranty	10 years
	15-20 years
Multi-group	Max. 5 systems in parrallel
Safety	IEC62619/CE/UN38.3
Hazardous materials classification	Class 9
TRANSPORTATION	UN38.3

HANO HN-HVS5 High Voltage Stackable Home Energy Storage System 10.24kWh-30.72kWh Lithium Battery1.png

Detailed selling points
1. Flexible & Scalable Capacity
Built on 102.4V 50Ah individual battery modules, the system offers a flexible capacity range from 10.64kWh to 37.27kWh per tower. It supports paralleling up to 5 towers, allowing seamless capacity expansion to perfectly match diverse residential and commercial energy storage needs.

2. Premium LiFePO4 Chemistry
Utilizing high-quality Lithium Iron Phosphate (LiFePO4) cells, the system ensures exceptional thermal stability and safety. It delivers an impressive cycle life of over 6,000 cycles at 80% Depth of Discharge (DOD), providing reliable energy storage for 15 to 20 years.

3. Intelligent Built-in BMS
The integrated Battery Management System (BMS) within the HVS control box offers comprehensive real-time monitoring and multi-layered protection against overcharge, over-discharge, overcurrent, short circuits, and temperature extremes, guaranteeing safe and efficient operation.

4. Robust Safety Certifications
Engineered with safety as a top priority, the system holds an IP20 protection rating and is fully certified to international standards including IEC62619, CE, and UN38.3. It is classified as a Class 9 hazardous material for transportation, ensuring full global compliance.

5. High-Performance Power Delivery
Designed for high efficiency, the system supports a maximum charging and discharging current of 100A. Its low internal impedance (≤1Ω) minimizes energy loss during conversion, while the wide operating temperature range (-10°C to 55°C for discharge) ensures consistent performance in various climates.

6. Space-Saving Modular Design
The stackable, vertical architecture significantly reduces the installation footprint, making it ideal for space-constrained environments. The sleek, all-in-one design not only looks modern but also simplifies installation and future maintenance.

Brief selling points
Scalable Architecture: 10.64kWh to 37.27kWh per tower, expandable up to 5 towers in parallel.
Long Cycle Life: >6,000 cycles @80% DOD, ensuring a 15-20 year service life.
Advanced Safety: Built-in BMS, IP20 rated, and fully certified (IEC62619/CE/UN38.3).
High Power Output: Supports 100A max charge/discharge current with low internal resistance.
Wide Temperature Range: Operates reliably from -10°C to 55°C (discharge).
Easy Installation: Compact, stackable modular design for quick setup and maintenance.

Product Brief Introduction

The HANO HN-HVS5 High Voltage Stackable Home Energy Storage System is an ultra-reliable power backup tailored for modern residential and light commercial grid challenges. Engineered as a high-efficiency High Voltage Stackable System, the HANO HN-HVS5 allows installers to customize single-tower capacities from 10.24kWh up to 30.72kWh. Built with long-lasting LiFePO4 Home Energy Storage cells (102.4V 50Ah per module), this robust Modular Lithium Battery Bank bypasses heavy parallel conversion losses. Featuring wide hybrid inverter compatibility, an Intelligent BMS Lithium Battery controller, and seamless Multi Tower Parallel Battery expansion up to 5 systems, it provides a stable asset for Commercial and Residential Energy Backup deployments worldwide.

Comprehensive Product Description

Sourcing clean energy storage that handles heavy startup loads without huge voltage drops is a common hurdle for solar distributors. HANO engineered the HANO HN-HVS5 High Voltage Stackable Home Energy Storage System to eliminate typical low-voltage installation pain points, such as thick copper cabling and high line losses. By stacking 2 to 6 modular 102.4V blocks vertically in series, this elite High Voltage Stackable System reaches a high operating voltage scope spanning from 204.8V up to 614.4V. This series-connected design interfaces directly with the high-voltage DC bus of top-tier inverters, boosting whole-system round-trip power efficiency while minimizing unnecessary thermal conversion stress.

Logistics and field technicians will find this Modular Lithium Battery Bank to be a massive labor cost saver. Its compact stack-type architecture cuts down installation time because there are no messy external battery wires to route or crimp. Driven by stable, premium LiFePO4 Home Energy Storage cells, HANO ensures reliable performance across wide temperature boundaries. The control box houses an Intelligent BMS Lithium Battery matrix that communicates via CAN/RS485 data paths, enabling engineering teams to execute local diagnostic checks and monitor multi-unit telemetry easily.

Key Structural Features

Flexible Modular Scaling: Supports stacking 2 to 6 modules per tower. This allows field teams to build scalable capacities of 10.24, 15.36, 20.48, 25.6, or 30.72kWh, keeping local warehouse SKU pressure very low.

Elite LiFePO4 Chemistry: Utilizing high-purity lithium iron phosphate cells, this LiFePO4 Home Energy Storage powerhouse easily registers >6,000 deep cycles at 80% Depth of Discharge (DOD) at 25°C, ensuring a 15-to-20-year service lifespan.

Smart Multi-Tower Paralleling: For larger energy requirements, the system supports a Multi Tower Parallel Battery layout, linking up to 5 complete towers together to reach a massive 153.6kWh setup.

Clean Stack Setup: The vertical stack configuration minimizes installation floor space, allowing it to fit effortlessly into tight electrical closets or garage corners.

Technical Advantages & Deep Expert Analysis

To see why the HANO HN-HVS5 High Voltage Stackable Home Energy Storage System outperforms traditional low-voltage setups, look at the engineering math behind heat losses. According to Joule's Law, pushing high power at a low voltage requires a massive current , which increases thermal losses exponentially. By opting for a High Voltage Stackable System, HANO keeps the current tight while stepping up the system voltage. The system operates smoothly with a recommended current of 50A and supports a maximum continuous charge and discharge current of 100A.

Furthermore, this Modular Lithium Battery Bank features an exceptionally low internal impedance of ≤1Ω . Low internal resistance directly prevents internal heat buildup during heavy power draws, protecting the structural integrity of the cells. Managed by a proactive Intelligent BMS Lithium Battery core, the system dynamically balances the voltage across all cells in the series string (64S to 192S). This deep monitoring optimizes charging curves and guards against overcharging, delivering a durable financial asset for microgrid developers.

Target Scenario Applications

Commercial and Residential Energy Backup: Perfect for high-end residential estates, luxury villas, and small offices looking to maximize solar self-consumption and cut high peak utility demand charges.

High-Capacity Scalable Microgrids: Ideal for remote properties or agricultural sites using a Multi Tower Parallel Battery layout to run heavy equipment during grid outages or off-grid operations.

Off-Peak Tariff Shaving: Allows small retail shops or workshops to charge this high-efficiency Modular Lithium Battery Bank during cheap off-peak hours and discharge during expensive daytime slots to cut overhead costs.

B2B Commercial Value

For international solar distributors and wholesalers, efficient inventory management determines structural profit margins. Stocking the HANO HN-HVS5 High Voltage Stackable Home Energy Storage System cuts the need to manage various standalone battery variants. This flexible High Voltage Stackable System lets you address multiple job scopes using identical modular blocks, streamlining your supply chain overhead.

Because HANO built this as an open-protocol platform, it syncs smoothly with leading high-voltage hybrid inverters worldwide. Supported by strict CE, IEC62619, and UN38.3 documentation, HANO ensures rapid customs clearance and fast local utility approvals, helping your sales team secure large Commercial and Residential Energy Backup contracts with complete peace of mind.
